LV463.7/4-150-M8.3 Fiber optic amplifier

LV463.7/4-150-M8.3
Compact fiber optic amplifier with integrated time function and LED light source.
  • SKU
    2110-50119070
  • Manufacturer code
    50119070
  • Switching frequency
    2500 Hz
  • Type of electric connection
    Connector M8
  • Degree of protection (IP)
    IP50
  • Number of contact energized outputs with signalling function
    0
  • Analogue output 0 V ... 10 V
    false
  • Analogue output 0 mA ... 20 mA
    false
  • Analogue output 4 mA ... 20 mA
    false
  • Analogue output -10 V ... +10 V
    false
  • Type of switching output
    PNP
  • With blanking function
    false
  • Operation agent-safety class
    Safety class 0
  • Rated control supply voltage DC
    12 - 24 V
  • Voltage type
    DC
    DC
    DC
    DC
  • Width amplifier
    10 mm
  • Height amplifier
    31.5 mm
  • Length amplifier
    72 mm
  • Indication
    LED
  • Setting procedure
    Manual adjustment
  • Construction type housing
    Cuboid
  • No-load current
    40 mA
  • Type of light
    Polarity free red light
  • Max. output current
    100 A
  • Ambient temperature
    -10 - 55 °C
  • Housing material
    Plastic
    Plastic
    Plastic
    Plastic
  • Material of cable sheath
    Other
  • Material fibre optics core
    Other
  • With time function
    false
  • Number of semiconductor outputs with signalling function
    1
  • Type of switch function
    Programmable/configurable
  • Switching frequency (Hz)
    2500
  • Supplyoltage (V)
    12 ... 24
  • Operational controls
    Slide switch
    Rocker pressure switch
  • Display
    LED
  • Special version
    Time function
  • Manufacturer Leuze

Product attachments

DS_LV463_en_50118006 (LINK)
