KRTM 20M/V-12-0004-S12

This contrast sensor features autocollimation, crop mark system, and a time function. It is designed with an RGB LED light source and operates within a range of 12 mm ± 1 mm. The sensor supports a supply voltage of 12 to 30 V DC and includes both analog and digital outputs.

SKU

2110-50133896
Manufacturer code

50133896
Number of semiconductor outputs with signalling function

1
Number of contact energized outputs with signalling function

1
Type of electric connection

Connector M12
Type of switching output

PNP
Type of switch function

Other
With blanking function

false
Operation agent-safety class

Safety class 3
Rated control supply voltage DC

12 - 30 V
Voltage type

DC
DC
DC
DC
Width sensor

30 mm
Height of sensor

80 mm
Length of sensor

53 mm
Setting procedure

Parameterization
Construction type housing

Cuboid
Laser protection class

Other
No-load current

0 mA
Type of light

Multi-coloured LED
With fibre optics connection

false
Switching frequency

16000 Hz
Degree of protection (IP)

Other
Ambient temperature

-25 - 60 °C
With exchange lens

false
Material of optical surface

Other
Housing material

Other
Metal
With time function

false
Most suitable applications

Crop mark detection High-speed sensing tasks
Special version

Autocollimation
Time function
Crop mark system
Supplyoltage (V)

12 ... 30
Switching frequency (Hz)

16000
Operational controls

Membrane keyboard
Via service interface
Analog outputs

1
Analog output

Current
Operating range (m)

0.012

Manufacturer Leuze

Product attachments

DSw_KRT20_fmt_08e_en (LINK)
