KRTM 20M/P-50-6320-S12

This contrast sensor features autocollimation, synchronization input, and time function, making it highly effective for precise applications. It utilizes an RGB LED light source and offers a digital switching output with a PNP transistor that's light/dark switchable. The sensor is housed in durable metal with a membrane keyboard for operational controls.

SKU

2110-50116177
Manufacturer code

50116177
Number of semiconductor outputs with signalling function

1
Type of electric connection

Connector M12
Type of switching output

PNP
Type of switch function

Other
With blanking function

false
Operation agent-safety class

Safety class 3
Rated control supply voltage DC

12 - 30 V
Voltage type

DC
DC
DC
DC
Width sensor

30 mm
Height of sensor

80 mm
Length of sensor

53 mm
Setting procedure

Manual adjustment
Construction type housing

Cuboid
Laser protection class

Other
No-load current

0 mA
Type of light

Multi-coloured LED
With fibre optics connection

false
Switching frequency

50000 Hz
Degree of protection (IP)

IP67
Ambient temperature

-25 - 60 °C
With exchange lens

false
Material of optical surface

Other
Housing material

Other
Metal
With time function

false
Special version

Autocollimation
Time function
Synchronization input
Supplyoltage (V)

12 ... 30
Switching frequency (Hz)

50000
Operational controls

Membrane keyboard
Operating range (m)

0.05

Manufacturer Leuze

Product attachments

DS_KRTM20Mhighres_en_50113452_01 (LINK)
