Start/stop and reset functions available
Thermoplastic enclosure
slender shock-proof enclosure
to be fitted to commercial-off-the-shelf aluminium profiles
to be installed at an ergonomic favourable position
large range of Illuminated pushbuttons, Selector switches, LED indicator lights, Key-operated selector switches and Emergency-Stop buttons
Field labelling with separate plastic cover

Manufacturer code

ott734385c2tnj93t8551544zb61rn
Type of Execution, for degree of pollution VDE 0100

3
Type of Execution, Overvoltage category IEC/EN 60664-1

III
Depth, General

39 mm
Height, General

99 mm
Width, General

40 mm
Housing material

Plastic, glass-fibre reinforced thermoplastic, self-extingui
Standard, climatic stress

DIN EN 60068
Standard, standards

EN IEC 60947-5-1
EN IEC 60947-1
Note, Ordering data

Notice: see ordering code
PIM maintenance status

Discharge "Online catalog"
Temperature, Ambient temperature[generated product variant]

-25 ... +65 °C
Temperature, ambient temperature, maximum

65 °C
Temperature, ambient temperature, minimum

-25 °C
Web Type

Product range
CAD, traceparts, product ID

69-06122012-076344
Colour, upper part of the enclosure

Black
Type of Execution, Overvoltage category VDE 0100

3
Type of electric connection

Connector plug M12, 8-pole

This product is unavailable

This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.
Manufacturer Schmersal
