BN 85-R-1824-3 5,0M Magnetic Reed switch

BN 85-R-1824-3 5,0M
Mounting with clamping brackets and sheathed cable
Non-contact principle
1 Reed contakts
Long life
Actuating distance up to 40 mm depending on actuating magnet and version
40 mm x 35 mm x 16,5 mm
Thermoplastic enclosure
Reed-contact to clip-in, on-location assembly
  • SKU
    4030661023564
  • Manufacturer code
    101114790
  • Current, Switching current, maximum
    1 A
  • Type of execution, Actuating element
    Magnet
  • Construction type housing
    Block
  • Type of Execution, IP Protection class, General
    IP40
  • Type of Execution, Mechanical life, minimum,
    1000000000 Operations
  • Type of Execution, Switching output, Digital output, electric
    Reed contacts
  • Height, Sensor
    35 mm
  • Length, Sensor
    16.5 mm
  • Width, Sensor
    40 mm
  • Housing material
    Glass-fibre, reinforced thermoplastic
  • Note, General
    The opening and closing functions depend on the direction of
  • PIM maintenance status
    Discharge "Online catalog"
  • Power, switching capacity, maximum
    30 VA
  • Type of switch function
    bistable contact
  • Type of electric connection
    Cable
  • SAP, basic quantity unit
    Piece
  • SAP, EAN (European Article Number)
    4030661023564
  • SAP, product group
    Initial
  • SAP, gross weight
    115.000 g
  • SAP, net weight
    115.000 g
  • Temperature, Ambient temperature[generated product variant]
    +0 ... +75 °C
  • Temperature, ambient temperature, maximum
    75 °C
  • Temperature, ambient temperature, minimum
    0 °C
  • Time, Bounce duration, maximum
    0.2 ms
  • Web Type
    Product range
  • Type of application, Actuating panel
    front side
  • Type of execution, mounting
    Mounting with clamping foot and sheathed cable
  • Diameter, Wire cross-section, AWG
    18 AWG
  • Diameter, Wire cross-section,
    0.75 mm<sup>2</sup>
  • Cable length
    5 m
  • Material, cable mantle
    LiY
  • Notice, Switch distance Sn
    Actuating distance up to 40 mm depending on version and actu
  • Number, cable wires, indication with cable cross-section, electrical
    2
  • Recommendation, actuator
    BP 10 S
    2x BP 10 S
    BP 15 S
    BP 34 S
    BP 20 S
    BP 31 S
    BP 11 S
    BP 12 S
    BP 6 S
    BP 8 S
    2 x BP 15 S
  • Review, area, switch distance Sn
    2 mm … 40 mm
    BP 6S = 2 … 12 mm
    BP 8S = 2 … 10 mm
    BP 10S = 5 … 20 mm
    2 x BP 10S = 6 … 27 mm
    BP 15S = 5 … 22 mm
    2 x BP 15S = 7 … 28 mm
    BP 34S = 10 … 40 mm
    BP 20S = 3 ... 28 mm
    BP 31S = 4 ... 30 mm
    BP 11S = 4 ... 23 mm
    BP 12S = 5 ... 27 mm
  • Review, restistance to shock
    60 g, on sine wave oscillation
  • Included in delivery, number and type, general
    Actuator must be ordered separately.
  • Selection (Yes/No),
    Yes
  • Number, Snap-in contacts
    1
  • Selection (Yes/No), latching
    Yes
  • Type of Execution, Active area
    lateral
  • Voltage, Switching voltage, VDC, maximum
    60 VDC

  • This product is unavailable

    This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.

  • Manufacturer Schmersal

Product attachments

file-24920-c44c9c1b351751a4936b1c2ac52b74aa.pdf (PDF, 121.3 kB)
