BN 31-RZ-1978-2 Magnetic Reed switch

BN 31-RZ-1978-2
1 Reed contakts
Non-contact principle
Actuation from side
Flat design
Actuating surface and direction of actuation marked by switch symbol
88 mm x 25 mm x 13 mm
Thermoplastic enclosure
Actuating distance up to 60 mm depending on actuating magnet and version
2 reed contacts
  • SKU
    4030661024882
  • Manufacturer code
    101127663
  • Current, Switching current, maximum
    3 A
  • Type of execution, Actuating element
    Magnet
  • Construction type housing
    rectangular
  • Type of Execution, IP Protection class, General
    IP67
  • Type of Execution, Mechanical life, minimum,
    1000000000 Operations
  • Type of Execution, Switching output, Digital output, electric
    Reed contacts
  • Height, Sensor
    25 mm
  • Length, Sensor
    13 mm
  • Width, Sensor
    88 mm
  • Housing material
    Glass-fibre, reinforced thermoplastic
  • Note, General
    The opening and closing functions depend on the direction of
    When the switches and actuators come together, the colours m
    The switch is to be mounted on iron with a non-magnetic laye
  • PIM maintenance status
    Discharge "Online catalog"
  • Power, switching capacity, maximum
    80 W
  • Type of electric connection
    Connector M8
  • SAP, basic quantity unit
    Piece
  • SAP, EAN (European Article Number)
    4030661024882
  • SAP, product group
    Initial
  • SAP, gross weight
    22.000 g
  • SAP, net weight
    22.000 g
  • Temperature, Ambient temperature[generated product variant]
    -25 ... +75 °C
  • Temperature, ambient temperature, maximum
    75 °C
  • Temperature, ambient temperature, minimum
    -25 °C
  • Web Type
    Product range
  • Type of execution, mounting
    Enclosure with mounting slots
  • Diameter, Wire cross-section, AWG
    18 AWG
  • Diameter, Wire cross-section,
    0.75 mm<sup>2</sup>
  • Distance, Repeat accuracy R R
    0.25 mm
  • Material, cable mantle
    H03VV-F
  • Movement, actuating speed, maximum
    18 m/s
  • Notice, Switch distance Sn
    Actuating distance up to 60 mm depending on actuating magnet
  • Number, cable wires, indication with cable cross-section, electrical
    2
  • Recommendation, actuator
    BP 10 S
    2x BP 10 S
    BP 15 S
    BP 34 S
    BP 20 S
    BP 31 S
    BP 11 S
    2x BP 11 S
    BP 12 S
    BP 21 S
    2x BP 21 S
    BP 10 N
    2x BP 10 N
    BP 15 N
    2 x BP 15/2 N
    2x BP 15/2 S
    BP 34 N
    BP 20 N
    BP 31 N
    BP 11 N
  • Review, Resistance to vibrations to EN 60068-2-6
    10 … 55 Hz, amplitude 1 mm
  • Review, restistance to shock
    30 g / 11 ms
  • Included in delivery, number and type, general
    Actuator must be ordered separately.
  • Selection (Yes/No),
    Yes
  • Number, Snap-in contacts
    1
  • Selection (Yes/No), latching
    Yes
  • Selection (Yes/No), Traceparts
    Yes
