Mounting with clamping brackets and 2 single wires
Actuation from front
Non-contact principle
1 Reed contakts
Long life
Actuating distance up to 40 mm depending on actuating magnet and version
40 mm x 35 mm x 16,5 mm
Thermoplastic enclosure
Reed-contact to clip-in, on-location assembly

SKU

4030661023472
Manufacturer code

101091836
Current, Switching current, maximum

1 A
Type of execution, Actuating element

Magnet
Construction type housing

Block
Type of Execution, IP Protection class, General

IP40
Type of Execution, Mechanical life, minimum,

1000000000 Operations
Type of Execution, Switching output, Digital output, electric

Reed contacts
Height, Sensor

35 mm
Length, Sensor

16.5 mm
Width, Sensor

40 mm
Housing material

Glass-fibre, reinforced thermoplastic
Note, General

The opening and closing functions depend on the direction of
PIM maintenance status

Discharge "Online catalog"
Power, switching capacity, maximum

30 W
Type of switch function

bistable contact
Type of electric connection

Cable
SAP, basic quantity unit

Piece
SAP, EAN (European Article Number)

4030661023472
SAP, product group

Initial
SAP, gross weight

40.000 g
SAP, net weight

40.000 g
Temperature, Ambient temperature[generated product variant]

+0 ... +75 °C
Temperature, ambient temperature, maximum

75 °C
Temperature, ambient temperature, minimum

0 °C
Time, Bounce duration, maximum

0.2 ms
Web Type

Product range
Type of application, Actuating panel

front side
Type of execution, mounting

clamping foot and 2 single wires
Diameter, Wire cross-section, AWG

18 AWG
Diameter, Wire cross-section,

0.75 mm<sup>2</sup>
Cable length

1 m
Material, cable mantle

LiY
Movement, actuating speed, maximum

18 m/s
Notice, Switch distance Sn

Actuating distance up to 40 mm depending on actuating magnet
Number, cable wires, indication with cable cross-section, electrical

2
Recommendation, actuator

BP 10 S
2x BP 10 S
BP 15 S
BP 34 S
BP 20 S
BP 31 S
BP 11 S
BP 12 S
BP 6 S
BP 8 S
2 x BP 15 S
Recommendation, Actuator, Lift switchgear

BP 10
2 x BP 15
BP 15
2 x BP 10
BP 34
BP 6
Review, area, switch distance S_n

2 mm … 40 mm
BP 6S = 2 … 12 mm
BP 8S = 2 … 10 mm
BP 10S = 5 … 20 mm
2 x BP 10S = 6 … 27 mm
BP 15S = 5 … 22 mm
2 x BP 15S = 7 … 28 mm
BP 34S = 10 … 40 mm
BP 20S = 3 ... 28 mm
BP 31S = 4 ... 30 mm
BP 11S = 4 ... 23 mm
BP 12S = 5 ... 27 mm
Review, restistance to shock

60 g, on sine wave oscillation
Included in delivery, number and type, general

Actuator must be ordered separately.
Selection (Yes/No),

Yes
Number, Snap-in contacts

1
Selection (Yes/No), latching

Yes
Voltage, Switching voltage, VDC, maximum

60 VDC
