Ultrasonic Sensor, Diffuse Mode Sensor, Operating voltage 15…30 VDC, Max. range 3000 mm, Smooth sonic transducer face, Cylindrical housing M30, potted, Connection via M12 x 1 male, Measuring range adjustable via teach button/Easy-Teach, Temperature compensation, Blind zone: 30 cm, Range: 300 cm, Resolution: 1 mm, Aperture angle of sonic cone: ±15 °, 1 × switching output, PNP/NPN, 1 × analog output, 4…20 mA / 0…10 V / additional switching output, PNP/NPN, NO/NC programmable, Transmission of process value and parametrization via IO-link, ATEX II 3 G approval, Gases and vapors, Group IIC, Zone 2, Dust, Group IIIC, Zone 22, When used in hazardous areas, the special conditions of the approval must be observed, SC-M12/3GD safety clips are included in delivery and prevent inadvertent disconnection of the energized cable

SKU

4047101373677
Manufacturer code

1610074
Length of sensor

89 mm
Ambient temperature

-25 - 45 °C
Supply voltage

15 - 30 V
Switching frequency

3.3 Hz
Diameter sensor

30 mm
Measuring range length

300 - 3000 mm
No-load current

50 mA
Relative repeat accuracy

0.15 %
Relative linearity deflection

0.5 %
Type of electric connection

Plug-in connection
Type of switching output

PNP/NPN
Type of switch function

Programmable/configurable
Setting procedure

Manual adjustment
Construction type housing

Cylinder, screw-thread
Standard for interfaces

Other
Material active area of sensor

Plastic
Housing material

Stainless steel
Type of analogy output

4 mA ... 20 mA
Explosion safety category for gas

ATEX gas-ex-protection, Cat. 3G
Explosion safety category for dust

ATEX dust-ex-protection, Cat. 3D
Connector gender

male
NO/NC

NO/NC contacts
Switching output

PNP/NPN
Network protocol

IO-link

Manufacturer Turck
