The sensors of the thermoMETER CS series are non-contact infrared temperature sensors designed for well-emitting objects (plastics, wood, ceramics, liquids). They measure the infrared radiation emitted by objects and calculate the surface temperature based on this information.

SKU

7965-4800556
Manufacturer code

4800556
Protection class

IP63
Supply voltage

4 mA (without LED); 10 mA (5 to 30 VDC)
Analog output

0 to 10 V,
Temperature range

-40 ... 400 °C
Optical resolution

15:1
Spectral range

8 ... 14 µm
Response time

14 ms to 999 s, adjustable
Temperature resolution

0,05 °C
System accuracy

±1,5 % or ±1,5 °C
Signal processing

Peak hold, valley hold, average; extended hold function with threshold and hysteresis
Max. operating temperature

-20 °C to 80 °C {°C}
