The sensors of the thermoMETER CS series are non-contact infrared temperature sensors designed for well-emitting objects (plastics, wood, ceramics, liquids). They measure the infrared radiation emitted by objects and calculate the surface temperature based on this information.

SKU

7965-4800517
Manufacturer code

4800517
Protection class

IP65 sensor head
Supply voltage

4...20 mA (5 to 30 VDC)
Analog output

4 mA ... 20 mA
Interface

mono-/bidirectional, 9.6 kBaud, 0/3 V level, alternative USB (optional)
Temperature range

-40 °C to 1030 °C
Optical resolution

15:1
Spectral range

8 ... 14 µm
Response time

30 ms
Temperature resolution

0,1 °C
System accuracy

±1 % or ±1 °C
Signal processing

Peak hold, valley hold, average; extended hold function with threshold and hysteresis
Max. operating temperature

Sensor: -20 °C to 120 °C, Controller: -20 °C to 75 °C {°C}
