FCS-K20-AP8X-H1141/3M Flow Monitoring, Immersion Sensor with Integrated Processor

FCS-K20-AP8X-H1141/3M

Flow Monitoring, Immersion Sensor with Integrated Processor, Operating voltage 19.2…28.8 VDC, Immersion sensor, Cable length 3 m, Flow sensor for gaseous media, Calorimetric principle, Adjustment via potentiometer, Mounting flange, plastic, included, Status display via 2-color LED, Plastic sensor housing, DC 3-wire, 19.2…28.8 VDC, NO contact, PNP output, Cable device with molded M12 × 1 male connector

  • SKU
    4047101447538
  • Manufacturer code
    100001097
  • Measurement principle
    Thermal
  • Type of process connection
    Flange connection
  • Compressive strength measuring head
    1 bar
  • Type of electric connection
    Plug-in connection
  • Ambient temperature for evaluation electronic
    0 - 60 °C
  • Rated control supply voltage Us at DC
    19.2 - 28.8 V
  • Voltage type for actuating
    DC
  • Adjustable setting value for flow for gases
    0.5 - 15 m/s
  • Type of switch function
    NO contact
  • Type of switching output
    PNP
  • Connector gender
    male
  • Cable length (m)
    3
  • Manufacturer Turck

Product attachments

file-51399-5a0b2ee83c578280f3c2e5ceb1a2affe.pdf (PDF, 109.84 kB)
