VS4EVQ Photoelectric Sensor, Opposed Mode Sensor (Emitter), Miniature Sensor

VS4EVQ

Photoelectric Sensor, Opposed Mode Sensor (Emitter), Miniature Sensor, Operating voltage 10…30 VDC, Max. range 1000 mm, Cable length 0.15 m, Cable with male end, PVC, M8 × 1, 3-pin, 150 mm, Protection class IP67, Operating voltage: 10…30 VDC, Flat design, Visible red light

  • SKU
    0662488694272
  • Manufacturer code
    3069427
  • Type of electric connection
    Connector M8
  • Construction type housing
    Cuboid
  • Width sensor
    4.75 mm
  • Height of sensor
    25.4 mm
  • Length of sensor
    12.5 mm
  • Material of optical surface
    Plastic
  • Ambient temperature
    -20 - 55 °C
  • Response time
    1 s
  • Suitable for safety functions
    false
  • Degree of protection (IP)
    IP67
  • Rated switching distance
    1000 mm
  • Max. switching distance
    1000 mm
  • Wavelength of the sensor
    660 nm
  • Type of light
    Polarity free red light
  • Material of cable sheath
    Polyvinyl chloride (PVC)
  • Housing material
    Plastic
  • Connector gender
    male
  • Cable length (m)
    0.15

  • This product is unavailable

    This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.

  • Manufacturer Turck

Product attachments

file-49929-a5ac198bab108c5241ef3020d73954dd.pdf (PDF, 201.03 kB)
