AM-T100 TOF cameras

AM-T100
Time-of-Flight Technologie (ToF)
Millimetre-accurate 3D depth images through Sony DepthSense™ technology
High frame rate up to 60 fps
Viewing area of 67° x 51
Range up to 6 m
Software for easy configuration of 3D monitoring areas
Use in manufacturing processes, logistics and robotics
Standardised GenICam data interface
Optimally adaptable to different ambient and mounting conditions
  • SKU
    4030661621302
  • Manufacturer code
    103048766
  • Type of Execution, Communication, Protocol, Transfer rate
    10/100/1000 Mbps Ethernet
    GigE Vision 2.0 Compliant
  • Type of Execution, CPU
    Dual Cortex-A53 1.2 GHz
  • Type of Execution, IP Protection class, General
    IP67
  • Type of Execution, Laser class
    1
  • Type of execution, Sensor, Resolution
    640 x 480 Pixel
  • Type of execution, sensor, topology
    iTOF
  • Distance, Accuracy, Sensor maximum
    1 %
  • Distance, Resolution, Sensor
    1 mm
  • Length, Wave length, sensor
    850 nm
  • Area, range, protection field, maximum
    6 m
  • Web Produktneutheit (Datum bis)
    2024-04-01
  • Standard, standards
    EN IEC 60825-1
    EN 61326-1
  • Note, IP Protection class, General
    when both plug connections are closed
  • Note, Area, range, protection field, maximum
    Depending on the remission properties of the target objects,
  • Note, Ambient temperature, minimum
    The camera can be operated from a temperature of -20° C afte
  • Note, operating voltage, DC
    PoE: IEEE802.3bt
  • PIM maintenance status
    Discharge "Online catalog"
  • Power, electrical consumption
    15 W
  • Power, electrical consumption, maximum
    40 W
  • Electrical data, Terminal, Connector, Transmitter, General
    X-coded M12 Ethernet connector
    Connector, M12, 8-pole, A-coded
  • SAP, basic quantity unit
    Piece
  • SAP, EAN (European Article Number)
    4030661621302
  • SAP, product group
    HAWA: Electromechanical switchgear
  • SAP, gross weight
    565.400 g
  • SAP, net weight
    565.400 g
  • Temperature, Ambient temperature[generated product variant]
    +0 ... +45 °C
  • Temperature, ambient temperature, maximum
    45 °C
  • Temperature, ambient temperature, minimum
    0 °C
  • Temperature, storage and transport temperature,[generated product variant]
    -20 ... +85 °C
  • Temperature, storage and transport temperature, maximum
    85 °C
  • Temperature, storage and transport temperature, minimum
    -20 °C
  • Time, Exposure, Sensor
    1 µs - 1 ms
  • Time, Frame rate, Sensor
    60 Hz
  • Tolerance, operating voltage, DC, maximum
    10 %
  • Tolerance, operating voltage, DC, minimum
    -10 %
  • Operating voltage
    24 VDC
  • Web Type
    Product range
  • Selection (Yes/No), CADENAS
    Yes
  • Selection (Yes/No), Traceparts
    Yes

  • This product is unavailable

    This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.

  • Manufacturer Schmersal
