SEP09.0.1.0.22/95 Two-hand control panel

SEP09.0.1.0.22/95
2 black operating buttons (positioning parts) Ø 55 mm
Aluminium enlosure
with removable aluminium cover at the bottom
for separate mounting of the actuators for the two-hand control
  • SKU
    4250116203246
  • Manufacturer code
    101022849
  • Housing color
    RAL 7004
  • Current, Thermal test current
    10 A
  • Current, Utilisation category AC-15
    8 A
  • Current, Utilisation category DC-13
    5 A
  • Type of Execution, IP Protection class, General
    IP54
  • Type of Execution, Mechanical life, minimum,
    10000000 Operations
  • Depth, General
    150 mm
  • Height, General
    160 mm
  • Width, General
    155 mm
  • Electrical data, Cable section, maximum
    1.5 mm²
  • Electrical data, Utilisation category
    DC-13
    AC-15
  • Material, sealing plates
    Aluminium
  • Housing material
    Aluminium
  • Material, enclosure coating
    powder-coated
  • Standard, standards
    EN IEC 60947-5-1
    EN ISO 13850
    EN IEC 60947-1
    EN ISO 13851
  • Note, Dimension, General
    Per enclosure
  • Note, General
    Optional: actuators with low actuating force
    1 NO/1 NC contact per unit
  • Note, Number, Operating push buttons
    Consisting of: EDP55SW; EF10.1; EF03.1
  • Number, NC contacts
    2
  • Number, NO contacts
    2
  • Number, Operating push buttons (positioning parts)
    2
  • PIM maintenance status
    Discharge "Online catalog"
  • PNV, standard, certificates
    cULus
  • Recommendation, product combination
    SRB201ZH
    SRB200ZHX1
    SRB 201ZHX3
  • Review, general dimensions (length, width, height, etc.)
    Operating push buttons (positioning parts): 55 mm
  • Type of electric connection
    Screw terminals M20 x 1.5
  • SAP, basic quantity unit
    Piece
  • SAP, EAN (European Article Number)
    4250116203246
  • SAP, product group
    Initial
  • SAP, gross weight
    3500.000 g
  • SAP, net weight
    3500.000 g
  • Voltage, rated insulation voltage
    440 V
  • Voltage, Utilisation category AC-15
    250 VAC
  • Voltage, Utilisation category DC-13
    24 VDC
  • Web Type
    Product range
  • Selection (Yes/No), Construction kit possible
    Yes
