Left-hand side locking cylinder
with two actuating heads
Aluminium enlosure
Protection class IP65

Manufacturer code

sog734948aa5nuzouck42938ugxefw
Housing color

Red
Colour of the key

Silver
Colour, key head

Silver
Type of Execution, IP Protection class, General

IP65
Type of Execution, Mechanical life, minimum,

100000 Operations
Housing material

Aluminium / chromated steel
Standard, standards

EN IEC 60947-5-1
Note, General

Notice: with two actuating heads for double doors, not for v
Note, Ordering data

Note: In the order/enquiry, the required key bit numbers "x1
PIM maintenance status

Discharge "Online catalog"
Temperature, Ambient temperature[generated product variant]

-25 ... +70 °C
Temperature, ambient temperature, maximum

70 °C
Temperature, ambient temperature, minimum

-25 °C
Web Type

Product range
Height, General

135 mm
Length, General

43 mm
Width, General

87 mm
Clamping force

1250 N
Latching force

5 N
Material, cylinder lock

Steel
Material, enclosure coating

painted
Note, applications

sliding safety guard
removable guard
hinged safety guard
Number, Actuating directions

4
Number, Keys

1
Review, restistance to shock

30 g / 18 ms
Temperature, storage and transport temperature,[generated product variant]

-40 ... +80 °C
Temperature, storage and transport temperature, maximum

80 °C
Temperature, storage and transport temperature, minimum

-40 °C

This product is unavailable

This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.
Manufacturer Schmersal
