Ultrasonic Sensor, Diffuse Mode Sensor, Operating voltage 15…30 VDC, Max. range 1300 mm, Smooth sonic transducer face, Cylindrical housing M30, potted, Connection via M12 × 1 male connector, Measuring range adjustable via Easy-Teach, Temperature compensation, Blind zone: 15 cm, Range: 130 cm, Resolution: 1 mm, Aperture angle of sonic cone: ±16 °, 2 x switching outputs, PNP, NO/NC programmable

SKU

4047101287349
Manufacturer code

1610034
Length of sensor

75 mm
Ambient temperature

-25 - 70 °C
Supply voltage

15 - 30 V
Switching frequency

6.9 Hz
Diameter sensor

30 mm
Measuring range length

150 - 1300 mm
No-load current

50 mA
Relative repeat accuracy

0.15 %
Relative linearity deflection

0.5 %
Type of electric connection

Plug-in connection
Type of switching output

PNP
Type of switch function

Programmable/configurable
Construction type housing

Cylinder, screw-thread
Material active area of sensor

Plastic
Housing material

Other
Connector gender

male
NO/NC

NO/NC contacts
Switching output

PNP

Manufacturer Turck
