BIM-NST-Y1X Magnetic Field Sensor, For Pneumatic Cylinders

BIM-NST-Y1X

Magnetic Field Sensor, For Pneumatic Cylinders, Cable length 2 m, Plastic, PA12-GF30, Magnetic-inductive sensor, DC 2-wire, nom. 8.2 VDC, Output acc. to DIN EN 60947-5-6 (NAMUR), Cable connection, ATEX category II 2 G, Ex Zone 1, ATEX category II 1 D, Ex Zone 20, SIL 2 (Low Demand Mode) acc. to IEC 61508, PL c acc. to ISO 13849-1 at HFT0, SIL 3 (All Demand Mode) acc. to IEC 61508, PL e acc. to ISO 13849-1 with redundant configuration HFT1

  • SKU
    4047101064223
  • Manufacturer code
    1058400
  • Type of actuation
    Magnet
  • Type of electric connection
    Cable
  • Type of switching output
    NAMUR
  • Width sensor
    17 mm
  • Height of sensor
    14 mm
  • Length of sensor
    28 mm
  • Construction type housing
    Cuboid
  • Housing material
    Plastic
  • Ambient temperature
    -25 - 70 °C
  • Voltage type
    DC
  • Degree of protection (IP)
    IP67
  • Explosion safety category for gas
    ATEX gas-ex-protection, Cat. 2G
  • Explosion safety category for dust
    ATEX dust-ex-protection, Cat. 1D
  • SIL according to IEC 61508
    2
  • Performance level according to EN ISO 13849-1
    Level c
  • Suitable for safety functions
    true
  • Atex category
    ATEX category II 1 D
    ATEX category II 2 G
  • Approvals / Compliance
    SIL 2
    SIL 3
  • Cable length (m)
    2
  • Manufacturer Turck

Product attachments

file-43757-e44f1087de5ad0f13b61915a388f81f8.pdf (PDF, 261.22 kB)
