RI360P1-QR14-ELU4X2/S97 Inductive Angle Sensor, With Analog Output For Use in Vehicle Board Nets, Premiu

RI360P1-QR14-ELU4X2/S97

Inductive Angle Sensor, With Analog Output For Use in Vehicle Board Nets, Premium Line, Operating voltage 8…30 VDC, Cable length 2 m, Rectangular, plastic, Many mounting possibilities, P1-Ri-QR14 included in delivery, For vehicle board nets, 12 V and 24 V, Increased interference immunity 30V/m following the e1 type approval, Immune to conducted interference acc. to DIN ISO 7637-2 (SAE J 113-11), Extended temperature range, High protection class IP68/IP69K, Protection against salt spray and rapid temperature change, Measuring range displayed via LED, Immune to electromagnetic interference, Resolution, 12-bit, 3‐wire, 8…30 VDC, Analog output, Programmable measuring range, 0.5…4.5 V, Cable connection

  • SKU
    4047101274325
  • Manufacturer code
    1590855
  • Type of electric connection
    Cable
  • Standard for interfaces
    Analogue
  • Housing material
    Plastic
  • Degree of protection (IP)
    IP68
  • Model
    Other
  • Physical measurement principle
    Inductive
  • Type of shaft encoder
    Hollow shaft
  • Diameter axle
    6 - 6.35 mm
  • Programmable
    true
  • Approvals / Compliance
    E1 type approval
  • Cable length (m)
    2
  • Manufacturer Turck

Product attachments

file-34606-2d64eae850093067b297250bd542adee.pdf (PDF, 607.64 kB)
