M12NR Photoelectric Sensor, Opposed Mode Sensor (Emitter/Receiver)

M12NR

Photoelectric Sensor, Opposed Mode Sensor (Emitter/Receiver), Operating voltage 10…30 VDC, Max. range 5000 mm, Cable length 2 m, Cable, PVC, 2 m, 4-wire, Protection classes IP67 / IP68, Metal housing, LED all-round visible, Indication of insufficient excess gain, Sensitivity adjustable via potentiometer, Operating voltage: 10…30 VDC, NPN switching output, changeover

  • SKU
    0662488772000
  • Manufacturer code
    3077200
  • Setting procedure
    Other
  • Type of electric connection
    Cable
  • Type of switching output
    NPN
  • Type of switch function
    Change-over contact (NO/NC)
  • Length of sensor
    67.5 mm
  • Material of optical surface
    Plastic
  • Ambient temperature
    -20 - 60 °C
  • Response time
    0.625 s
  • Switching frequency
    500 Hz
  • Suitable for safety functions
    false
  • Degree of protection (IP)
    IP67
  • Rated switching distance
    5000 mm
  • Max. switching distance
    5000 mm
  • Wavelength of the sensor
    660 nm
  • Diameter sensor
    12 mm
  • Material of cable sheath
    Polyvinyl chloride (PVC)
  • Housing material
    Metal
  • Type of switching output
    NPN
  • Cable length (m)
    2

  • This product is unavailable

    This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.

  • Manufacturer Turck

Product attachments

file-40630-ffaca2568bf9a58d2861ccc168ad672a.pdf (PDF, 337.35 kB)
