M12APRQPMA20 Photoelectric Sensor, Opposed Mode Sensor (Emitter/Receiver)

M12APRQPMA20

Photoelectric Sensor, Opposed Mode Sensor (Emitter/Receiver), Operating voltage 10…30 VDC, Max. range 5000 mm, Cable length 0.15 m, Cable with male end M12 × 1, 4-pin, PUR, 150 mm, Protection classes IP67 / IP68, Metal housing, LED all-round visible, Indication of insufficient excess gain, Sensitivity adjustable via potentiometer, Operating voltage: 10…30 VDC, PNP switching output (PIN 4), light operation, PIN 2 not assigned

  • SKU
    0662488956332
  • Manufacturer code
    3095633
  • Type of electric connection
    Connector M12
  • Type of switching output
    PNP
  • Type of switch function
    Change-over contact (NO/NC)
  • Construction type housing
    Cylinder, screw-thread
  • Length of sensor
    67.5 mm
  • Sensing mode
    Light switching
  • Material of optical surface
    Plastic
  • Ambient temperature
    -20 - 60 °C
  • Switching frequency
    500 Hz
  • Suitable for safety functions
    false
  • Degree of protection (IP)
    IP67
  • Rated switching distance
    5000 mm
  • Max. switching distance
    5000 mm
  • Diameter sensor
    12 mm
  • Material of cable sheath
    Polyurethane (PUR)
  • Housing material
    Metal
  • Type of switching output
    PNP
  • Connector gender
    male
  • Cable length (m)
    0.15

  • This product is unavailable

    This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.

  • Manufacturer Turck

Product attachments

file-34633-68ea70bd63240071640219bf8fcd3961.pdf (PDF, 358.41 kB)
