M12PLVQ8 Photoelectric Sensor, Retroreflective Sensor

M12PLVQ8

Photoelectric Sensor, Retroreflective Sensor, Operating voltage 10…30 VDC, Max. range 2500 mm, Male M12 × 1, 4-pin, Protection classes IP67 / IP68, Metal housing, LED all-round visible, Indication of insufficient excess gain, Sensitivity adjustable via potentiometer, Operating voltage: 10…30 VDC, PNP switching output, complementary contact

  • SKU
    0662488771874
  • Manufacturer code
    3077187
  • Rated switching distance
    2500 mm
  • Max. switching distance
    2500 mm
  • With reflector
    false
  • Type of electric connection
    Connector M12
  • Type of switching output
    PNP
  • Type of switch function
    Change-over contact (NO/NC)
  • Length of sensor
    74 mm
  • Material of optical surface
    Plastic
  • Ambient temperature
    -20 - 60 °C
  • Response time
    0.5 s
  • Switching frequency
    1000 Hz
  • Wavelength of the sensor
    660 nm
  • Type of light
    Polarity free red light
  • Suitable for safety functions
    false
  • Degree of protection (IP)
    IP67
  • Setting procedure
    Other
  • Diameter sensor
    12 mm
  • Housing material
    Metal
  • Connector gender
    male
  • Type of switching output
    PNP

  • This product is unavailable

    This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.

  • Manufacturer Turck

Product attachments

file-50196-c8e3a37503cd9ce8b35d64bd541fd99f.pdf (PDF, 431.96 kB)
