Q26PXLP Photoelectric Sensor, Retroreflective Sensor with Polarizing Filter, For Clear O

Q26PXLP

Photoelectric Sensor, Retroreflective Sensor with Polarizing Filter, For Clear Object Detection, Operating voltage 12…30 VDC, Max. range 800 mm, Cable length 2 m, Light or dark operation, adjustable, Sensitivity adjusted via potentiometer, Coaxial optics, reduced blind zone, Operating voltage: 10…30 VDC, PNP switching output, Switching output for insufficient excess gain

  • SKU
    0662488867058
  • Manufacturer code
    3086705
  • Rated switching distance
    800 mm
  • Max. switching distance
    800 mm
  • Type of electric connection
    Cable
  • Type of switching output
    PNP
  • Type of switch function
    Normally open contact (NO)
  • Construction type housing
    Cuboid
  • Width sensor
    14 mm
  • Height of sensor
    42 mm
  • Length of sensor
    25 mm
  • Sensing mode
    Light switching
    Dark switching
  • Material of optical surface
    Glass
  • Ambient temperature
    -10 - 55 °C
  • Wavelength of the sensor
    660 nm
  • Type of light
    Polarized red light
  • Suitable for safety functions
    false
  • Degree of protection (IP)
    IP67
  • Housing material
    Plastic
  • Type of switching output
    PNP
  • Cable length (m)
    2

  • This product is unavailable

    This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.

  • Manufacturer Turck

Product attachments

file-34886-85e9b1676d95eea8927d0beb7c4b5439.pdf (PDF, 83.93 kB)
