PRK 92/3 L Ex Polarized retro-reflective photoelectric sensor

PRK 92/3 L Ex
Polarized retro-reflective photoelectric sensor with Ex-protection, suitable for various environments.
  • SKU
    2110-50080723
  • Manufacturer code
    50080723
  • Pre failure notice
    false
  • With time function
    false
  • Rated switching distance
    5000 mm
  • Max. switching distance
    5000 mm
  • With reflector
    false
  • Analogue output 0 V ... 10 V
    false
  • Analogue output 0 mA ... 20 mA
    false
  • Analogue output 4 mA ... 20 mA
    false
  • Analogue output -10 V ... +10 V
    false
  • With other analogue output
    false
  • With communication interface analogue
    false
  • With communication interface AS-Interface
    false
  • With communication interface CANOpen
    false
  • With communication interface DeviceNet
    false
  • With communication interface Ethernet
    false
  • With communication interface INTERBUS
    false
  • With communication interface PROFIBUS
    false
  • With communication interface RS-232
    false
  • With communication interface RS-422
    false
  • With communication interface RS-485
    false
  • With communication interface SSD
    false
  • With communication interface SSI
    false
  • Number of protected semiconductor outputs
    0
  • Type of electric connection
    Connector M12
  • Type of switching output
    Other
  • Operation agent-safety class
    Safety class 2
  • Explosion safety category for gas
    ATEX gas-ex-protection, Cat. 2G
  • Explosion safety category for dust
    ATEX dust-ex-protection, Cat. 2D
  • Construction type housing
    Cuboid
  • Width sensor
    20 mm
  • Height of sensor
    80 mm
  • Length of sensor
    42.2 mm
  • Material of optical surface
    Glass
  • Housing material
    Metal
    Metal
    Metal
    Metal
  • Min. reflector distance
    200 mm
  • Ambient temperature
    -20 - 50 °C
  • Response time
    0 s
  • Switching frequency
    60 Hz
  • Rated control supply voltage DC
    5.5 - 13 V
  • Voltage type
    DC
    DC
    DC
    DC
  • With monitoring function downstream switching devices
    false
  • Laser protection class
    None
  • Wavelength of the sensor
    0 nm
  • Type of light
    Polarity free red light
  • With restart blockage
    false
  • Suitable for safety functions
    false
  • Degree of protection (IP)
    IP67
  • Special version
    Ex-protected
  • Supplyoltage (V)
    5.5 ... 13
  • Construction type housing
    Cubic
  • Ambient temperature, operation (°C)
    -20 ... 50
  • Operating range limit (m)
    0.2 ... 5
  • Interface
    NAMUR
  • Ex device category
    2
  • Manufacturer Leuze

Product attachments

PAL_PRK92Ex_en_50111475 (LINK)
