QS18VP6LDQ8 Photoelectric Sensor, Diffuse Mode Laser Sensor

QS18VP6LDQ8

Photoelectric Sensor, Diffuse Mode Laser Sensor, Operating voltage 10…30 VDC, Max. range 300 mm, Male M12 × 1, 4-pin, Protection class IP67, LED all-round visible, Sensitivity adjusted via potentiometer, Operating voltage: 10…30 VDC, PNP switching output, changeover

  • SKU
    0662488730451
  • Manufacturer code
    3073045
  • Type of electric connection
    Connector M12
  • Type of switching output
    PNP
  • Type of switch function
    Change-over contact (NO/NC)
  • Construction type housing
    Cuboid
  • Width sensor
    15 mm
  • Height of sensor
    35 mm
  • Length of sensor
    31 mm
  • Material of optical surface
    Plastic
  • Ambient temperature
    -10 - 50 °C
  • Response time
    0.7 s
  • Switching frequency
    700 Hz
  • Laser protection class
    Class 1
  • Wavelength of the sensor
    650 nm
  • Type of light
    Polarity free red light
  • Suitable for safety functions
    false
  • Degree of protection (IP)
    IP67
  • Material of cable sheath
    Polyvinyl chloride (PVC)
  • Max. switching distance
    300 mm
  • Diameter sensor
    18 mm
  • Housing material
    Plastic
  • Type of switching output
    PNP
  • Connector gender
    male

  • This product is unavailable

    This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.

  • Manufacturer Turck

Product attachments

file-38347-d77764cdb1f6e8497ef47940b58b6166.pdf (PDF, 665.23 kB)
