ILD1320-500Unavailable Laseroptical displacement sensor

ILD1320-500
optoNCDT 1220 is a compact laser triangulation sensor designed for precise measurement of distance, displacement, and position. It can be quickly and easily set up using function keys or the web interface.
  • SKU
    7965-4120277
  • Manufacturer code
    4120277
  • Measuring range
    500 mm
  • Type of electric connection
    integrated cable 3 m, open ends
  • Measuring rate (adjustable)
    0,25 kHz / 0,5 kHz / 1 kHz / 2 kHz / 4kHz
  • Linearity
    < ±600 µm … ±1200 µm
  • Repeatability
    50 µm
  • Protection class
    IP67
  • Dimensions
    46x30x20
  • Supply voltage
    11 … 30 VDC
  • Signal output
    RS422
  • Setting procedure
    PC software
  • Analog output
    4 mA ... 20 mA
  • Digital interface
    RS422

  • This product is unavailable

    This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.

  • Manufacturer Micro Epsilon

Product attachments

https://www.micro-epsilon.com/fileadmin/download/products/dat--optoNCDT-1220-1320-1420--en.pdf (LINK)
