BI20R-Q14-LU-H1141 Inductive Sensor, With Analog Output

BI20R-Q14-LU-H1141

Inductive Sensor, With Analog Output, Operating voltage 15…30 VDC, Rectangular, height 14 mm, Plastic, PBT‐GF30‐V0, Sensitivity adjusted via potentiometer, Thickness measurement (e.g. screws, rivets, rods), Path measurement with conical actuator: Measuring range freely adjustable via cone length, 3‐wire, 15…30 VDC, Analog output, 0…10 V, M12 x 1 male connector

  • SKU
    4047101072297
  • Manufacturer code
    1535548
  • Operating voltage
    15 - 30 V
  • Supply voltage
    15 - 30 V
  • Limiting frequency
    80 Hz
  • Type of electric connection
    Plug-in connection
  • Type of analogy output
    0 V ... 10 V
  • Housing material
    Plastic
  • Construction type housing
    Special construction
  • Length of sensor
    62.5 mm
  • Ambient temperature
    -25 - 70 °C
  • Degree of protection (IP)
    IP67
  • Width sensor
    30 mm
  • Height of sensor
    14 mm
  • Connector gender
    male
  • Manufacturer Turck

Product attachments

file-54403-1d96b9cfe4f56ffc785d2c9665a9aabe.pdf (PDF, 389.58 kB)
