MAHE51A Measuring Light Screen, Emitter

MAHE51A

Measuring Light Screen, Emitter, Operating voltage 11.4…14 VDC, Max. range 1800 mm, Minimum target size 2.5 mm, Scan field 1300 mm, Max. sensing range 1.8 m, Operating voltage 11.8…12.2 VDC (from controller), Protection class IP65, Adjustment via software

  • SKU
    0662488626570
  • Manufacturer code
    3062657
  • Type of electric connection
    Connector 7/8 inch
  • Scope of delivery of the one-way system
    Transmitter
  • Ambient temperature
    0 - 50 °C
  • Wavelength of the sensor
    880 nm
  • Width sensor
    38.1 mm
  • Height of sensor
    1377 mm
  • Length of sensor
    38.1 mm
  • Resolution of the light curtain
    2.5 mm
  • Height, Protection field
    1300 mm
  • Suitable for safety functions
    false

  • This product is unavailable

    This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.

  • Manufacturer Turck

Product attachments

file-41084-2c629b04bc4a8c477251706bfc515a27.pdf (PDF, 208.43 kB)
