MSI 420-01 Safety control

MSI 420-01

Functions: Modularly expandable safety control, 24 safe I/Os, 4 configurable safe I/Os (via software), 40 certified function modules, Configuration via mini USB or Ethernet (TCP/IP), Expandable with up to 12 I/O modules, Freely configurable with MSI.designer (license-free), Program memory in SD card format (512 MB), Switching current 4 A per output, Transfer of diagnostic data via external fieldbus gateways, Up to 300 function modules in a project; SIL: 3, IEC 61508; Performance Level (PL): Up to and including e, EN ISO 13849-1; Category: 4, EN ISO 13849; Number of outputs: 4 Piece(s); Number of inputs: 16 Piece(s); Service interface: Ethernet; Connection: Screw terminal; Dimension: 45 mm x 96.5 mm x 121 mm; Certifications: TÜV Rheinland, c UL US

  • SKU
    2110-50132986
  • Manufacturer code
    50132986
  • Type of electric connection
    Insulation displacement connection
  • Rail mounting possible
    true
  • Wall mounting/direct mounting
    false
  • Front built-in possible
    true
  • Rack-assembly possible
    true
  • Voltage type (supply voltage)
    DC
  • Supply voltage DC
    24 - 24 V
  • Max. number of integrated analogue inputs
    0
  • Max. number of integrated analogue outputs
    0
  • Number of relay outputs
    0
  • Number of channels
    4
  • Parameterizable
    false
  • Integrated configuration function
    false
  • Programmable
    false
  • Expandable
    true
  • With detachable clamps
    false
  • On delay timer
    false
  • Off delay timer
    false
  • With function restart blockage
    false
  • With automatic feeding
    false
  • Function contacter monitoring
    false
  • Function emergency stop
    false
  • Function contactless working protection installation
    false
  • Function affirm pushbutton
    false
  • Function 2-hand switching
    false
  • Function operating mode selection
    false
  • Function access control
    false
  • Number of slots
    32
  • Suitable for safety functions
    true
  • SIL according to IEC 61508
    3
  • Performance level according to EN ISO 13849-1
    Level e
  • Appendant operation agent (Ex ia)
    false
  • Appendant operation agent (Ex ib)
    false
  • Explosion safety category for gas
    None
  • Explosion safety category for dust
    None
  • Width
    45 mm
  • Height
    96.5 mm
  • Depth
    121 mm
  • Number of outputs (pcs)
    4
  • Number of inputs (pcs)
    16
  • Performance Level (PL)
    Up to and including e
  • Category
    4
  • ISO Standard
    EN ISO 13849
    EN ISO 13849-1
  • Manufacturer Leuze

Product attachments

DS_MSI-420-01_eng_50132986 (LINK)
