1 Cable entry M 20 x 1.5
Thermoplastic enclosure
one-side operation
wire up to 10 m long
Release push button
Position indicator
Large wiring compartment
Twisting of towing eye not possible
wire pull and breakage detection
One tension force for cable lengths up to 10 m

SKU

4030661352671
Manufacturer code

101192478
Current, Thermal test current

10 A
Current, Utilisation category AC-15

4 A
Current, Utilisation category DC-13

4 A
Type of Execution, IP Protection class, General

IP67
Type of Execution, Mechanical life, minimum,

1000000 Operations
Switching principle

Snap action
Length, wire, maximum

10 m
Electrical data, Cable section, maximum

2.5 mm²
Electrical data, Cable section, minimum

0.75 mm²
Electrical data, Max. fuse rating

6 A gG D-fuse
Electrical data, Utilisation category

DC-13
AC-15
Material, contacts, electrical

Silver
Housing material

Glass-fibre, thermoplastic
Material, housing cover

Glass-fibre, thermoplastic
Standard, standards

EN IEC 60947-5-1
EN IEC 60947-5-5
EN ISO 13850
Note, Electrical Data, Cable section

All indications including the conductor ferrules.
Note, General

Recommended cable lengths for pull-wire Emergency-Stop switc
As the thimbles are subject to deformation in case of wire p
At 2 m ... 5 m distance intermediate wire supports are requi
Number, Safety contacts

2
PIM maintenance status

Discharge "Online catalog"
PNV, standard, certificates

TÜV
Type of switch function

Opener (NC)
Type of electric connection

Screw terminals M20 x 1.5
Safety parameters, Mission time

20 Year(s)
Safety parameter

EN ISO 13849-1
SAP, basic quantity unit

Piece
SAP, EAN (European Article Number)

4030661352671
SAP, product group

HAWA: Electromechanical switchgear
SAP, gross weight

217.000 g
SAP, net weight

217.000 g
Temperature, Ambient temperature[generated product variant]

-25 ... +70 °C
Temperature, ambient temperature, maximum

70 °C
Temperature, ambient temperature, minimum

-25 °C
Voltage, Rated impulse withstand voltage

6 kV
Voltage, rated insulation voltage

500 V
Voltage, Utilisation category AC-15

230 VAC
Voltage, Utilisation category DC-13

24 VDC
Web Type

Product range
Selection (Yes/No), Traceparts

Yes
Type of application, Relative humidity, maximum

95 %
Selection (Yes/No), CADENAS

Yes
Depth, General

50.9 mm
Height, General

160 mm
Width, General

40.5 mm

Manufacturer Schmersal
