Thermoplastic enclosure
Concealed mounting possible
Insensitive to transverse misalignment
88 mm x 25 mm x 13 mm
Long life
no mechanical wear
Insensitive to soiling

SKU

4030661026602
Manufacturer code

101114704
PIM maintenance status

Discharge "Online catalog"
SAP, basic quantity unit

Piece
SAP, EAN (European Article Number)

4030661026602
SAP, product group

Initial
SAP, gross weight

365.000 g
SAP, net weight

365.000 g
Coding, Coding level according to EN ISO 14119

Low
Current, Switching current, maximum

0.01 A
Type of execution, Actuating element

Magnet
Type of Execution, Terminals, mechanical

not flush
Type of Execution, IP Protection class, General

IP67
Type of Execution, Switching output, Digital output, electric

Miscellaneous, Reed contacts
Diameter, Wire cross-section, AWG

23 AWG
Diameter, Wire cross-section,

0.25 mm<sup>2</sup>
Height, Sensor

25 mm
Cable length

10 m
Length, Sensor

13 mm
Area, ensured switch distance OFF S_ar

15 mm
18 mm
Area, ensured switch distance ON S_ao

5 mm
8 mm
Width, Sensor

88 mm
Material, cable mantle

PVC
Housing material

Glass-fibre, reinforced thermoplastic
Motion, Direction of motion

Head-on to the active surface
Standard, standards

EN IEC 60947-5-3
BG-GS-ET-14
Note, General

Contact symbols shown for the closed condition of the guard
The contact configuration for versions with or without LED i
Number, NC contacts

1
Number, NO contacts

1
PNV, standard, certificates

cULus
TÜV
BG
Power, switching capacity, maximum

0.24 W
Recommendation, actuator

BPS 33-2326
BPS 33
Recommended, Safety switchgear

SRB-E-301ST
SRB-E-201LC
Review, Resistance to vibrations to EN 60068-2-6

10 … 55 Hz, amplitude 1 mm
Review, restistance to shock

30 g / 11 ms
Safety parameters, Mission time

20 Year(s)
Safety parameter

EN ISO 13849-1
Included in delivery, number and type, general

Actuator must be ordered separately.
Temperature, Ambient temperature[generated product variant]

-25 ... +70 °C
Temperature, ambient temperature, maximum

70 °C
Temperature, ambient temperature, minimum

-25 °C
Temperature, storage and transport temperature,[generated product variant]

-25 ... +70 °C
Temperature, storage and transport temperature, maximum

70 °C
Temperature, storage and transport temperature, minimum

-25 °C
Time, Switching frequency, maximum

5 Hz
Web Type

Product range
Selection (Yes/No), CADENAS

Yes
Review, selection (yes/no), Prerequisite evaluation unit

Yes
CAD, traceparts, product ID

33-22052019-077517
Number, Safety contacts

2
Number, cable wires, electrical

4

This product is unavailable

This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.
Manufacturer Schmersal
