MC336-S1C2-A

Magnetically coded sensor with a robust plastic housing and glass fiber reinforcement, designed for reliable performance in safety applications.

SKU

2110-63001050
Manufacturer code

63001050
Number of semiconductor outputs with signalling function

0
Number of contact energized outputs with signalling function

0
Number of protected semiconductor outputs

0
Number of protected contact energized outputs

0
Type of actuation

Magnet
Type of electric connection

Cable
Width sensor

26.2 mm
Height of sensor

13 mm
Length of sensor

36 mm
Explosion safety category for gas

None
Explosion safety category for dust

None
Construction type housing

Cuboid
Housing material

Plastic
Plastic
Plastic
Plastic
Glass fiber reinforced
Coating housing

Uncoated
Protected switch distance OFF

11 mm
Protected switch distance ON

3 mm
Max. output current at protected output

500 mA
Ambient temperature

-20 - 70 °C
Mechanical mounting condition for sensor

Other
Min. output current

500 mA
Voltage type

AC/DC
Cross-/short circuit identification possible

false
Switching distance

8 mm
With monitoring function downstream switching devices

false
Suitable for safety functions

true
With status indication

false
Degree of protection (IP)

IP67
Type of switch function

1NC + 1NO
External actuator

Magnetically coded
Cut-out point (OFF), min. (mm)

8

Manufacturer Leuze

Product attachments

DS_MC336-S1C2-A_eng_63001050 (LINK)
