MU25A-32 Motor protection circuit breaker, thermal 25-32A Magn. 384A

MU25A-32

Motor protection circuit breaker, thermal 25-32A Magn. 384A, with current limiter "MBS25-ID50" up to Icu= 50kA!

  • SKU
    9005738012500
  • Manufacturer code
    MU25A-32
  • Rated operation power at AC-3, 400 V
    15 kW
  • Overload release current setting
    25 - 32 A
  • Type of electrical connection of main circuit
    Screw connection
  • Degree of protection (IP)
    IP20
  • Adjustment range undelayed short-circuit release
    384 - 384 A
  • Thermal protection
    true
  • Phase failure sensitive
    true
  • Switch off technique
    Thermomagnetic
  • Rated operating voltage
    690 - 690 V
  • Rated permanent current Iu
    25 A
  • Rated operation power at AC-3, 230 V
    8 kW
  • Type of execution
    Push button
  • Device construction
    Built-in device fixed built-in technique
  • With integrated auxiliary switch
    false
  • With integrated under voltage release
    false
  • Number of poles
    3
  • Rated short-circuit breaking capacity lcu at 400 V, AC
    6 kA
  • Height
    80 mm
  • Width
    45 mm
  • Depth
    82 mm

  • This product is unavailable

    This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.

  • Manufacturer Benedict
