MU25A-16 Motor protection circuit breaker, thermal 10-16A Magn. 210A

MU25A-16

Motor protection circuit breaker, thermal 10-16A Magn. 210A, with current limiter "MBS25-ID50" up to Icu= 50kA!

  • SKU
    9005738681737
  • Manufacturer code
    MU25A-16
  • Rated operation power at AC-3, 400 V
    7.5 kW
  • Overload release current setting
    10 - 16 A
  • Type of electrical connection of main circuit
    Screw connection
  • Degree of protection (IP)
    IP20
  • Adjustment range undelayed short-circuit release
    192 - 192 A
  • Thermal protection
    true
  • Phase failure sensitive
    true
  • Switch off technique
    Thermomagnetic
  • Rated operating voltage
    690 - 690 V
  • Rated permanent current Iu
    25 A
  • Rated operation power at AC-3, 230 V
    4 kW
  • Type of execution
    Push button
  • Device construction
    Built-in device fixed built-in technique
  • With integrated auxiliary switch
    false
  • With integrated under voltage release
    false
  • Number of poles
    3
  • Rated short-circuit breaking capacity lcu at 400 V, AC
    6 kA
  • Height
    80 mm
  • Width
    45 mm
  • Depth
    82 mm
