K3-07ND04 24 Contactor relay 4NC, Coil 24VAC 50Hz

K3-07ND04 24

Contactor relay 4NC, Coil 24V 50/60Hz, selfcleaning doublecontacts suitable for electronic circuits - 17V, 5mA, ambient temperature rating from -40°C till +90°C, smallest sizes at maximum performance!

  • SKU
    9005738893222
  • Manufacturer code
    K3-07ND04 24
  • Mounting method
    DIN-rail/screw
  • Rated control supply voltage Us at AC 50HZ
    22 - 24 V
  • Rated control supply voltage Us at AC 60HZ
    24 - 27 V
  • Rated control supply voltage Us at DC
    0 - 0 V
  • Voltage type for actuating
    AC
  • Rated operation current Ie , 400 V
    2 A
  • Connection type auxiliary circuit
    Screw connection
  • Interface
    false
  • Number of auxiliary contacts as normally closed contact
    4
  • Number of auxiliary contacts as normally open contact
    0
  • Number of auxiliary contacts as normally closed contact, delayed switching
    0
  • Number of auxiliary contacts as normally open contact, leading
    0
  • With LED indication
    false
  • Number of auxiliary contacts as change-over contact
    0
  • Manual operation possible
    false

  • This product is unavailable

    This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.

  • Manufacturer Benedict
