K3-07ND40 110 Contactor relay 4NO, Coil 110VAc 50Hz

K3-07ND40 110

Contactor relay 4NO, Coil 110V 50Hz 110-120V 60Hz, selfcleaning doublecontacts suitable for electronic circuits - 17V, 5mA, ambient temperature rating from -40°C till +90°C, smallest sizes at maximum performance!

  • SKU
    9005738232809
  • Manufacturer code
    K3-07ND40 110
  • Mounting method
    DIN-rail/screw
  • Rated control supply voltage Us at AC 50HZ
    100 - 110 V
  • Rated control supply voltage Us at AC 60HZ
    110 - 122 V
  • Rated control supply voltage Us at DC
    0 - 0 V
  • Voltage type for actuating
    AC
  • Rated operation current Ie , 400 V
    2 A
  • Connection type auxiliary circuit
    Screw connection
  • Interface
    false
  • Number of auxiliary contacts as normally closed contact
    0
  • Number of auxiliary contacts as normally open contact
    4
  • Number of auxiliary contacts as normally closed contact, delayed switching
    0
  • Number of auxiliary contacts as normally open contact, leading
    0
  • With LED indication
    false
  • Number of auxiliary contacts as change-over contact
    0
  • Manual operation possible
    false
