Metal enclosure
two-side operation
wire up to 2 x 50 m long
Robust design
Low actuating force

Pull-ring reset
wire pull and breakage detection
Ex-Zone 21 and 22

SKU

4030661383804
Manufacturer code

101209694
CAD, traceparts, product ID

33-22052019-077570
Current, Thermal test current

10 A
Current, Utilisation category AC-15

2.5 A
Current, Utilisation category DC-13

6 A
Actuating element

Roller lever N300
Type of Execution, IP Protection class, General

IP65
IP66
Type of Execution, Mechanical life, minimum,

50000 Operations
Switching principle

Snap action
Electrical data, Cable section, maximum

1.5 mm²
Electrical data, Cable section, minimum

0.75 mm²
Electrical data, Max. fuse rating

6 A gG D-fuse
Electrical data, Utilisation category

DC-13
AC-15
Explosion protection parameters, category

2D
Explosion protection parameters, designation

D II 2D Ex tb IIIC T90°C Db
Explosion protection, regulations

EN IEC 60079-0
EN 60079-31
Explosion protection parameters, zones

21
Force, Positive break force, minimum Force,

50 N
Material, contacts, electrical

Silver
Housing material

Grey cast iron, painted
Standard, standards

EN IEC 60947-5-1
EN IEC 60947-5-5
EN ISO 13850
ABNT NBR IEC 60947-5-1
ABNT NBR IEC 60947-5-5
Note, Electrical Data, Cable section

All indications including the conductor ferrules.
Number, Auxiliary contacts

1
Number, Safety contacts

1
PIM maintenance status

Discharge "Online catalog"
PNV, standard, certificates

TÜV
CCC
CCC EX
Type of switch function

NO contact, NC contact
Type of electric connection

Screw terminals M20 x 1.5
Safety parameters, Mission time

20 Year(s)
Safety parameter

EN ISO 13849-1
SAP, basic quantity unit

Piece
SAP, EAN (European Article Number)

4030661383804
SAP, product group

Initial
SAP, gross weight

4550.000 g
SAP, net weight

4550.000 g
Temperature, Ambient temperature[generated product variant]

-20 ... +60 °C
Temperature, ambient temperature, maximum

60 °C
Temperature, ambient temperature, minimum

-20 °C
Voltage, Rated impulse withstand voltage

4 kV
Voltage, rated insulation voltage

250 VAC
Voltage, Utilisation category AC-15

230 VAC
Voltage, Utilisation category DC-13

24 VDC
Web Type

Product range
Note, General

At 3 m distance intermediate wire supports are required, see
Tightening torque, Positive break torque

0.18 Nm
Type of application, Actuating direction

Each time 75° right-hand side and left-hand side rotation
Angle, Positive break angle

32 °
Length, wire, maximum

50 m
Force, Actuating force, maximum

50 N
Material, housing cover

Grey cast iron, painted
Note, Force, Actuating Force

30 N in wire direction
Selection (Yes/No), Reset by pull ring

Yes

This product is unavailable

This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.
Manufacturer Schmersal
