Typ. operating range limit Sn: 2.5 mm; Operating range Sa: 0 ... 2 mm; Supply voltage: 10 ... 30 V, DC; Digital switching outputs: 1 Piece(s); Switching output 1: Transistor, PNP, NO (normally open); Switching frequency: 4,500 Hz; Connection: Cable, 2,000 mm, 3 -wire; Design, housing: Cylindrical; Thread size: M8; Dimensions: 8 mm x 35 mm; Type of installation: Non-embedded; Housing material: Stainless steel; Certifications: c UL US

SKU

2110-50109645
Manufacturer code

50109645
Length of sensor

35 mm
Diameter sensor

8 mm
Flush / Non-flush

Not flat
Switching distance

2 mm
Suitable for safety functions

false
Type of switch function

Normally open contact
Type of switching output

PNP
Type of electric connection

Cable
Number of semiconductor outputs with signalling function

1
Number of contact energized outputs with signalling function

0
Number of protected semiconductor outputs

0
Number of protected contact energized outputs

0
Type of actuation

Other
Type of interface

None
Type of interface for safety communication

None
Construction type housing

Cylinder, screw-thread
Coating housing

Other
Cascadable

false
SIL according to IEC 61508

None
Performance level according to EN ISO 13849-1

None
Max. output current at protected output

0 mA
Supply voltage

10 - 30 V
Rated control supply voltage DC

10 - 30 V
Voltage type

DC
DC
DC
DC
Switching frequency

4500 Hz
With monitoring function downstream switching devices

false
Housing material

Metal
Stainless steel
Compression-resistant

false
Explosion safety category for gas

None
Explosion safety category for dust

None
Supplyoltage (V)

10 ... 30
Design

Cylindrical
Switching frequency (Hz)

4500

Manufacturer Leuze
