BC5-QF5.5-Y1X/S250 Capacitive Sensor

BC5-QF5.5-Y1X/S250

Capacitive Sensor, Rated switching distance 5 mm, Flush, Rectangular, height 5.5 mm, Large active face, marked for correct installation, Plastic, PP, Fixed settings, DC 2-wire, nom. 8.2 VDC, Output acc. to DIN EN 60947-5-6 (NAMUR), Cable connection, ATEX category II 1 G, Ex zone 0, ATEX category II 1 D, Ex zone 20, SIL2 (Low Demand Mode) acc. to IEC 61508, PL c acc. to ISO 13849-1 with HFT0, SIL3 (All Demand Mode) acc. to IEC 61508, PL e acc. to ISO 13849-1 with redundant configuration HFT1

  • SKU
    4047101149241
  • Manufacturer code
    2030000
  • Length of sensor
    54 mm
  • Flush / Non-flush
    Concise
  • Switching distance
    5 mm
  • Type of switching output
    NAMUR
  • Type of electric connection
    Cable
  • Type of actuation
    Metallic Target
  • Type of interface for safety communication
    Other
  • Construction type housing
    Cuboid
  • SIL according to IEC 61508
    2
  • Max. output current at protected output
    2.1 mA
  • Supply voltage
    8.2 - 8.2 V
  • Voltage type
    DC
  • Switching frequency
    100 Hz
  • Explosion safety category for gas
    ATEX gas-ex-protection, Cat. 1G
  • Explosion safety category for dust
    ATEX dust-ex-protection, Cat. 1D
  • Type of interface
    Other
  • Width sensor
    20.3 mm
  • Height of sensor
    5.5 mm
  • Flush / Non-flush
    Flush
  • Housing material
    Plastic
  • Atex category
    ATEX category II 1 D
    ATEX category II 1 G
  • Manufacturer Turck

Product attachments

file-55423-103c781842b5733572243104d9fca0dd.pdf (PDF, 856.68 kB)
