BC3-M12-AP6X/S90/3GD Capacitive Sensor

BC3-M12-AP6X/S90/3GD

Capacitive Sensor, Rated switching distance 3 mm, Flush, Cable length 2 m, M12 × 1 threaded barrel, Chrome-plated brass, Fine adjustment via potentiometer, DC 3-wire, 10…30 VDC, NO contact, PNP output, Cable connection, ATEX category II 3 G, Ex zone 2, ATEX category II 3 D, Ex zone 22

  • SKU
    4047101090383
  • Manufacturer code
    2601003
  • Length of sensor
    63.5 mm
  • Diameter sensor
    12 mm
  • Flush / Non-flush
    Concise
  • Switching distance
    3 mm
  • Type of switch function
    Normally open contact
  • Type of switching output
    PNP
  • Type of electric connection
    Cable
  • Type of actuation
    Metallic Target
  • Type of interface for safety communication
    None
  • Construction type housing
    Cylinder, screw-thread
  • Coating housing
    Chromium-plated
  • Supply voltage
    30 - 30 V
  • Voltage type
    DC
  • Switching frequency
    100 Hz
  • Explosion safety category for gas
    ATEX gas-ex-protection, Cat. 3G
  • Explosion safety category for dust
    ATEX dust-ex-protection, Cat. 3D
  • Type of interface
    Other
  • Type of switch function
    NO contact
  • Type of switching output
    PNP
  • Rated control supply voltage Us at DC
    30 - 30
  • Flush / Non-flush
    Flush
  • Housing material
    Metal
  • Atex category
    ATEX category II 3 D
    ATEX category II 3 G
  • Cable length (m)
    2
  • Manufacturer Turck

Product attachments

file-46991-ca9b375a042a26cd4d7c45d6e324f706.pdf (PDF, 241.04 kB)
