LCS-2M12B-N06PNC-K020V Capacitive sensor

LCS-2M12B-N06PNC-K020V

Switching distance Sn: 1 ... 6 mm; Assured switching distance: 4.9 mm; Output function: PNP, NC (normally closed); Connection: Cable, 2,000 mm, 3 -wire; Design, housing: Cylindrical; Thread size: M12 x 1 mm; Dimensions: 12 mm x 55 mm

  • SKU
    2110-50136578
  • Manufacturer code
    50136578
  • Length of sensor
    55 mm
  • Diameter sensor
    12 mm
  • Flush / Non-flush
    Not flat
  • Switching distance
    4.9 mm
  • Suitable for safety functions
    false
  • Type of switch function
    Breaker contact
  • Type of switching output
    PNP
  • Type of electric connection
    Cable
  • Number of semiconductor outputs with signalling function
    1
  • Number of contact energized outputs with signalling function
    0
  • Number of protected semiconductor outputs
    0
  • Number of protected contact energized outputs
    0
  • Type of actuation
    Other
  • Type of interface for safety communication
    None
  • Construction type housing
    Cylinder, screw-thread
  • Coating housing
    Other
  • Cascadable
    false
  • SIL according to IEC 61508
    None
  • Performance level according to EN ISO 13849-1
    None
  • Max. output current at protected output
    0 mA
  • Supply voltage
    10 - 30 V
  • Rated control supply voltage DC
    10 - 30 V
  • Voltage type
    DC
  • Switching frequency
    100 Hz
  • With monitoring function downstream switching devices
    false
  • With status indication
    false
  • Housing material
    Metal
  • Compression-resistant
    false
  • Explosion safety category for gas
    None
  • Explosion safety category for dust
    None
  • Design
    Cylindrical
  • Switching distance Sn (mm)
    1 ... 6
  • Type of switch function
    PNP, NC
  • Manufacturer Leuze

Product attachments

DS_LCS-2M12B-N06PNC-K020V_eng_50136578 (LINK)
