Radar Sensor, Level Control, Operating voltage 17…33 VDC, Max. range 10000 mm, Range: 10 m, Blind zone: 35 cm, Resolution: 1 mm, Cone angle of the radar beam: ±3°, Distance, level, volume or % output, Approved according to ETSI 305550-2, Approved according to FCC/CFR. 47 Part 15., Male connector, M12 × 1, 4-pin, Operating voltage 18…33 VDC, Switching output switchable between PNP/NPN, Analog output switchable between 4…20 mA/0…10 V, Automatic current/voltage detection, IO-Link, 4-digit, 2-colored, 14-segment display, Housing is rotatable by 180° after mounting the process connection, Process connection NPT 1", Pressure resistance -1…16 bar rel.

SKU

4047101514469
Manufacturer code

100012723
Type of electric connection

Screw connection
Rated control supply voltage Us at DC

17 - 33 V
Voltage type for actuating

DC
Number of contacts as normally closed contact

5
Number of contacts as normally open contact

5
Number of contacts as change-over contact

5
Physical measurement principle

Other
Width

38 mm
Height

140.8 mm
Depth

38 mm
Connector gender

male
Type of switching output

PNP/NPN
Network protocol

IO-link
Rotatable

yes

Manufacturer Turck
