FCST-A4P-VRX/230VAC Freely Rotatable FCST Flow Sensor, Monitoring of Flow Speed, Relay Output 230 VA

FCST-A4P-VRX/230VAC

Freely Rotatable FCST Flow Sensor, Monitoring of Flow Speed, Relay Output 230 VAC NO NC, Operating voltage 207…253 VAC, Immersion sensor, Cable length 2 m, Thermodynamic operating principle, Flow monitoring, Switchpoint freely adjustable, Adjusted via potentiometer, LED band for indications, Relay switching output, 230 VAC NO/NC, Switchpoint freely adjustable, Freely rotatable sensor, Plugged in with adapter, Screw-in adapter, M18 x 1.5

  • SKU
    4047101303070
  • Manufacturer code
    6870254
  • Measurement principle
    Thermal
  • Type of process connection
    Thread connection
  • Adjustable setting value for flow for liquids
    1 - 150 m/s
  • Compressive strength measuring head
    100 bar
  • Type of electric connection
    Other
  • Ambient temperature for evaluation electronic
    -20 - 70 °C
  • Voltage type for actuating
    AC
  • Rated control supply voltage Us at AC 50HZ
    207 - 253 V
  • Rated control supply voltage Us at AC 60HZ
    207 - 253 V
  • Rotatable
    yes
  • Type of switch function
    NO/NC contacts
  • Cable length (m)
    2
  • Manufacturer Turck

Product attachments

file-39033-b0468ebf39ac250352ea25fc13fe5eba.pdf (PDF, 107.15 kB)
