Absolute Rotary Encoder - Single-Turn, Industrial Line, Operating voltage 10…30 VDC, Synchro flange, Ø 58 mm, Solid shaft, Ø 10 mm × 20 mm, Optical measuring principle, Shaft material: stainless steel, Protection class IP67 on housing and shaft side, ‐40…+85 °C, Max. 8000 rpm (continuous operation 5000 rpm), 10…30 VDC, SSI, gray, M12 × 1 male, 8-pin, 360° resolved in 13 bit (8192 positions)

SKU

4047101545579
Manufacturer code

100016318
Model

Other
Physical measurement principle

Optic
Type of electric connection

Plug-in connection
Diameter axle

10 - 10 mm
Housing material

Other
Degree of protection (IP)

IP67
Connector gender

male

Manufacturer Turck

Product attachments

file-40160-606a6e0611dec9ededb481f7d812664a.pdf (PDF, 207.58 kB)
