REM-191B6E-IOL32B-H1141 Absolute Rotary Encoder - Multiturn, IO-Link, Industrial Line

REM-191B6E-IOL32B-H1141

Absolute Rotary Encoder - Multiturn, IO-Link, Industrial Line, Operating voltage 18…30 VDC, Flange with stator coupling, Ø 46 mm, Blind hole hollow shaft, Ø 6 mm (plug-in depth max. 18.5 mm), Magnetic measuring principle, Shaft material: stainless steel, Protection class IP67 on housing and shaft side, ‐40…+85 °C, Max. 4000 rpm (continuous operation 2000 rpm), Energy harvesting technology, 18…30 VDC, M12 × 1 male connector, 4-pin, Singleturn resolution 14 bit scalable, default 14 bit, Multiturn resolution scalable only to 18 bits over total resolution, default 18 bits, Total resolution 32 bit scalable, default 32 bit

  • SKU
    4047101523775
  • Manufacturer code
    100018243
  • Model
    Other
  • Physical measurement principle
    Magnetic
  • Type of shaft encoder
    Hollow shaft
  • Type of electric connection
    Plug-in connection
  • Diameter axle
    6 - 6 mm
  • Housing material
    Other
  • Degree of protection (IP)
    IP67
  • Connector gender
    male
  • Network protocol
    IO-link
  • Manufacturer Turck

Product attachments

file-38559-2645dd9ff2e765d751eb1636694d4dac.pdf (PDF, 171.15 kB)
