SMI306EQ Photoelectric Sensor, Opposed Mode Sensor (Emitter)

SMI306EQ

Photoelectric Sensor, Opposed Mode Sensor (Emitter), Operating voltage 10…30 VDC, Max. range 140000 mm, Intrinsically safe(Ex ia), Operating temperature: -40 °C … +70 °C, Male connector MINI, 3-pin, Protection class IP67, Operating voltage: 10…30 VDC

  • SKU
    0662488352684
  • Manufacturer code
    3035268
  • Setting procedure
    Other
  • Type of electric connection
    Connector 7/8 inch
  • Length of sensor
    77.5 mm
  • Material of optical surface
    Plastic
  • Ambient temperature
    -40 - 70 °C
  • Response time
    10 s
  • Suitable for safety functions
    false
  • Degree of protection (IP)
    IP67
  • Rated switching distance
    140000 mm
  • Max. switching distance
    140000 mm
  • Wavelength of the sensor
    950 nm
  • Type of light
    Infrared light
  • Diameter sensor
    30 mm
  • Material of cable sheath
    Polyvinyl chloride (PVC)
  • Housing material
    Plastic
  • Connector gender
    male

  • This product is unavailable

    This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.

  • Manufacturer Turck

Product attachments

file-51842-a423fa5d71762f5ff077827a31fd341f.pdf (PDF, 489.45 kB)
