S186EQDP Photoelectric Sensor, Opposed Mode Sensor (Emitter)

S186EQDP

Photoelectric Sensor, Opposed Mode Sensor (Emitter), Operating voltage 10…30 VDC, Max. range 20000 mm, Cable length 0.15 m, M12 × 1 male connector, 4-pin, Protection classes IP67/IP69K, Ambient temperature: -40 °C…+70 °C, Operating voltage: 10…30 VDC

  • SKU
    0662488440190
  • Manufacturer code
    3044019
  • Type of electric connection
    Connector M12
  • Length of sensor
    78.7 mm
  • Material of optical surface
    Plastic
  • Ambient temperature
    -40 - 70 °C
  • Suitable for safety functions
    false
  • Degree of protection (IP)
    IP67
  • Rated switching distance
    20000 mm
  • Max. switching distance
    20000 mm
  • Wavelength of the sensor
    950 nm
  • Type of light
    Infrared light
  • Diameter sensor
    18 mm
  • Material of cable sheath
    Polyvinyl chloride (PVC)
  • Housing material
    Plastic
  • Connector gender
    male
  • Cable length (m)
    0.15

  • This product is unavailable

    This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.

  • Manufacturer Turck

Product attachments

file-49443-76486199814af7be0422a2a06972bc5f.pdf (PDF, 1014.23 kB)
