SM2A312DQD Photoelectric Sensor, Diffuse Mode Sensor

SM2A312DQD

Photoelectric Sensor, Diffuse Mode Sensor, Operating voltage 24…240 VAC, Max. range 380 mm, 1/2″ connector, Protection class IP67, Sensitivity adjustable via potentiometer, Alignment indicator, Operating voltage: 24…240 VAC, Switching output, bipolar, Light/dark operation

  • SKU
    0662488268411
  • Manufacturer code
    3026841
  • Type of electric connection
    Connector 1/2 inch
  • Type of switching output
    Relay contact
  • Construction type housing
    Cuboid
  • Width sensor
    12.2 mm
  • Height of sensor
    30.7 mm
  • Length of sensor
    84 mm
  • Sensing mode
    Light-/dark switching
  • Material of optical surface
    Plastic
  • Ambient temperature
    -20 - 70 °C
  • Response time
    8 s
  • Wavelength of the sensor
    650 nm
  • Type of light
    Infrared light
  • Suitable for safety functions
    false
  • Degree of protection (IP)
    IP67
  • Setting procedure
    Other
  • Material of cable sheath
    Polyvinyl chloride (PVC)
  • Max. switching distance
    380 mm
  • Diameter sensor
    18 mm
  • Housing material
    Plastic
  • Type of switching output
    PNP/NPN

  • This product is unavailable

    This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.

  • Manufacturer Turck

Product attachments

file-52608-9cbb354e37ab039329786ee6417d0567.pdf (PDF, 628.64 kB)
