QS18EN6DB Photoelectric Sensor, Diffuse Mode Sensor

QS18EN6DB

Photoelectric Sensor, Diffuse Mode Sensor, Operating voltage 10…30 VDC, Max. range 500 mm, Cable length 2 m, Cable, PVC, 2 m, 4-wire, Protection class IP67, LED all-round visible, Sensitivity adjusted via teach button, Operating voltage: 10…30 VDC, NPN switching output, Light or dark operation

  • SKU
    0662488687458
  • Manufacturer code
    3068745
  • Type of electric connection
    Cable
  • Type of switching output
    NPN
  • Type of switch function
    Normally open contact (NO)
  • Construction type housing
    Cuboid
  • Width sensor
    15 mm
  • Height of sensor
    35 mm
  • Length of sensor
    21.1 mm
  • Sensing mode
    Light switching
    Dark switching
  • Material of optical surface
    Plastic
  • Ambient temperature
    -20 - 70 °C
  • Response time
    0.6 s
  • Switching frequency
    833 Hz
  • Wavelength of the sensor
    940 nm
  • Type of light
    Infrared light
  • Suitable for safety functions
    false
  • Degree of protection (IP)
    IP67
  • Material of cable sheath
    Polyvinyl chloride (PVC)
  • Max. switching distance
    500 mm
  • Housing material
    Plastic
  • Type of switching output
    NPN
  • Cable length (m)
    2

  • This product is unavailable

    This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.

  • Manufacturer Turck

Product attachments

file-44332-df636c6460682bd11d733192ad181fb4.pdf (PDF, 366.57 kB)
