LM80KUQP Photoelectric Sensor, Laser Sensor, Diffuse Mode (Triangulation)

LM80KUQP

Photoelectric Sensor, Laser Sensor, Diffuse Mode (Triangulation), Operating voltage 10…30 VDC, Max. range 80 mm, Cable length 0.3 m, Stainless steel housing, Protection class IP67, Connection via 300 mm cable with connector, M12 × 1, 5-pin, Laser class 2, Visible red, 655 nm, Analog output accuracy: 0.002 mm, IO-Link accuracy: 0.175 mm, Range: 40…80 mm, Operating voltage: 10…30 VDC, Push/pull switching output or IO-Link, Analog output 0…10 V

  • SKU
    0662488083816
  • Manufacturer code
    3810218
  • Type of electric connection
    Connector M12
  • Type of switching output
    PNP/NPN
  • Type of switch function
    Normally open contact (NO)
  • Construction type housing
    Cuboid
  • Width sensor
    23.5 mm
  • Height of sensor
    48.5 mm
  • Length of sensor
    35.8 mm
  • Material of optical surface
    Other
  • Laser protection class
    Class 2
  • Type of light
    Polarity free red light
  • Degree of protection (IP)
    IP67
  • Material of cable sheath
    Polyvinyl chloride (PVC)
  • Supply voltage
    10 - 30
  • Standard for interfaces
    Other
  • Housing material
    Stainless steel
  • Network protocol
    IO-link
  • Cable length (m)
    0.3

  • This product is unavailable

    This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.

  • Manufacturer Turck

Product attachments

file-44114-25fd55013032feb7d519d3736f270c6e.pdf (PDF, 430.28 kB)
