Q20NDLQ5 Photoelectric Sensor, Diffuse-Mode Sensor

Q20NDLQ5

Photoelectric Sensor, Diffuse-Mode Sensor, Operating voltage 10…30 VDC, Max. range 800 mm, Cable length 0.15 m, Cable with male end, M12 × 1, 4-pin, PVC, 150 mm, Protection class IP67, LED, all-round visible, Sensitivity adjusted via potentiometer, Operating voltage: 10…30 VDC, NPN switching output, changeover

  • SKU
    0662488781880
  • Manufacturer code
    3078188
  • Type of electric connection
    Connector M12
  • Type of switching output
    NPN
  • Type of switch function
    Change-over contact (NO/NC)
  • Construction type housing
    Cuboid
  • Width sensor
    12 mm
  • Height of sensor
    32 mm
  • Length of sensor
    20 mm
  • Material of optical surface
    Plastic
  • Ambient temperature
    -20 - 60 °C
  • Response time
    0.8 s
  • Switching frequency
    600 Hz
  • Wavelength of the sensor
    655 nm
  • Type of light
    Polarity free red light
  • Suitable for safety functions
    false
  • Degree of protection (IP)
    IP67
  • Material of cable sheath
    Polyvinyl chloride (PVC)
  • Max. switching distance
    800 mm
  • Housing material
    Plastic
  • Type of switching output
    NPN
  • Connector gender
    male
  • Cable length (m)
    0.15

  • This product is unavailable

    This product is currently unavaliable, this could be due to a limited stock shortage, or because of discontinuation or replacement. For more information please contact us at b2b@tipteh.si.

  • Manufacturer Turck

Product attachments

file-42745-36f975cffc4ad4d690c6ca4fda48e49a.pdf (PDF, 573.32 kB)
